3D Laser Scanning & Modelling
RTC360 Product Specifications:
The RTC360 is a High-speed 3D laser scanner featuring an integrated HDR spherical imaging system and a visual inertial system (VIS) for real-time registration. This advanced scanner completes a full dome scan and captures a spherical HDR image in under 2 minutes at a resolution of 6 mm at 10 m. The system provides exceptional accuracy with 3D point precision as follows:
- 1.9 mm at 10 m
- 2.9 mm at 20 m
- 5.3 mm at 40 m
Key Projects:
N.E. Parrott Surveys Limited has extensive experience in 3D scanning and modelling across diverse industrial and technical applications. Projects include, but are not limited to:
· Interior Building Scans: Capturing and modelling interiors to support the design of air ventilation and dust collection systems.
· Crane Rail Projects: Pre-engineering services for beam replacement and alignment of crane rails.
· Piping Systems: As-built documentation, 3D modelling, isometric (ISO) drawing creation, installation analysis, and stress testing.
· Crime Scene Investigation: Development of accurate 3D models and floor plans to support forensic analysis.
· Apron Feeders: As-built scanning of liners, deformation inspections, and 3D modelling of feeders.
· Pocket Audits: Generation of 3D models to calculate and compare shotcrete volumes—both required and installed.
